ABB 1SDA067423R1
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
C.BREAKER TMAX XT1N 160 FIXED FOUR-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMD R 80-800 AXT1N 160 TMD 80-800 4p F F
ABB 1SDA067423R1 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
ABB EcoSolutions
- ABB EcoSolutions
- Yes
Additional Information
- CAD Dimensional Drawing
- 1SDH001295R0080
- Circuit Breaker Type to be Associated
- Power Distribution
- Connecting Capacity Main Circuit
- Busbar 45.5 ... 80 mm²
- Current Type
- AC/DC
- Electrical Durability
- 120 cycles per hour8000 cycle
- Mechanical Durability
- 240 cycles per hour25000 cycle
- Number of Poles
- 4
- Opening Time
- CB with SOR 15 msCB with UVR 15 ms
- Order Multiple
- 1 piece
- Power Loss
- at Rated Operating Conditions per Pole 4.8 W
- Product Main Type
- SACE Tmax XT
- Product Name
- Moulded Case Circuit Breaker
- Product Type
- Automatic Circuit Breaker
- Rated Current (In)
- 80 A
- Rated Frequency (f)
- 50 / 60 Hz
- Rated Impulse Withstand Voltage (Uimp)
- 8 kV
- Rated Instantaneous Short-Circuit Current Setting (Ii)
- 800 A
- Rated Insulation Voltage (Ui)
- 800 V
- Rated Operational Voltage
- 690 V AC500 V DC
- Rated Service Short-Circuit Breaking Capacity (Ics)
- (220 V AC) 50 kA(230 V AC) 50 kA(240 V AC) 50 kA(380 V AC) 36 kA(415 V AC) 36 kA(440 V AC) 18 kA(500 V AC) 15 kA(525 V AC) 11 kA(690 V AC) 5 kA(250 V DC) 2 Poles in Series 36 kA(500 V DC) 3 Poles in Series 36 kA
- Rated Ultimate Short-Circuit Breaking Capacity (Icu)
- (220 V AC) 65 kA(230 V AC) 65 kA(240 V AC) 65 kA(380 V AC) 36 kA(415 V AC) 36 kA(440 V AC) 36 kA(500 V AC) 30 kA(525 V AC) 22 kA(690 V AC) 6 kA(250 V DC) 2 Poles in Series 36 kA(500 V DC) 3 Poles in Series 36 kA
- Rated Uninterrupted Current (Iu)
- 160 A
- Rated Voltage (Ur)
- 690 V
- Recommended Screw Driver
- Main Circuit M6
- Release
- TMD
- Release Type
- TM
- Setting Range
- 56...80 A
- Short-Circuit Performance Level
- N
- Standards
- IEC
- Sub-type
- XT1
- Terminal Connection Type
- Front
- Terminal Type
- Bolt
- Tightening Torque
- 6 N·m
- Version
- F
Circular Value
- Circular Design Principles Recyclability Rate
- Design for Closing Resource Loops - Standard EN45555 - 60.9 %
- Conflict Minerals Reporting Template (CMRT)
- 9AKK108467A5658
- End of Life Instructions
- 9AKK108468A2347
- Group Waste to Landfill Target
- UL 2799 Zero Waste To Landfill Validation available
- Toxic Substances Control Act - TSCA
- 9AKK108467A8326
Classifications
- eClass
- V11.1 : 27370409
- ETIM 9
- EC000228 - Power circuit-breaker for trafo/generator/installation protection
- Object Classification Code
- Q
- WEEE Category
- 5. Small Equipment (No External Dimension More Than 50 cm)
Dimensions
- Product Net Depth / Length
- 70 mm
- Product Net Height
- 130 mm
- Product Net Weight
- 1.4 kg
- Product Net Width
- 101.6 mm
Eco Transparency
- Environmental Product Declaration - EPD
- 9AKK108468A1890
Environmental
- Environmental Information
- 9AKK107991A8215 9AKK108467A6707
- REACH Declaration
- 9AKK108466A1425
- RoHS Information
- 9AKK108466A1424
- RoHS Status
- Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
- SCIP
- 38ea6003-efeb-440b-8258-294c4647d79c Italy (IT)
- Simplified SCIP
- 13d4e4b4-a0b7-4b0e-a670-bf1e01e9dc3d Poland (PL)383e131d-8ac9-464b-891c-edec40806df8 Norway (NO)4edfba22-9fdd-4b59-8ab8-17d5ad0e1490 Finland (FI)fa2a42d4-3bc2-4227-a0c8-cd97d76849db Netherlands (NL)ed0d7f17-8e19-4ea9-a0c0-ae7a50079494 Germany (DE)d5a17c63-7902-4635-832b-0cb8363bedac Denmark (DK)f0964070-7e0c-4541-9359-2d1975aa9945 Germany (DE)54f8c0e4-78d5-4efc-bb4a-e7bf97518408 Croatia (HR)7508a0e6-9533-4ab0-bfe5-bc229327607a Czech Republic (CZ)a9f952fd-daf0-4a35-9c2f-b2a31a011ae8 Poland (PL)18281490-6f95-4f80-a336-0e6b162be180 Netherlands (NL)d308258b-32b9-4087-bf09-6a66e3109ef4 Netherlands (NL)0a45d19b-4a2a-440f-af7c-53ac264325b3 Estonia (EE)fdd57062-d9fc-4bfd-9079-4a3a96ea94b1 Greece (GR)fb836575-46ef-4da4-9067-d404dc5946bb Portugal (PT)c67644e0-dda8-4107-b8e9-978fdcebea28 Sweden (SE)11f8b80f-ea71-4297-a53f-4258d5d3b90f Germany (DE)1259445e-a1fd-4893-9b9f-08f9edc89b4f Germany (DE)92b4386c-e5ab-444f-95be-43e1758d7166 France (FR)5e4ea114-26ff-402c-acb5-2e5fc34e10d1 Netherlands (NL)8cffde16-12dc-4fce-933f-374d54f4fa47 Spain (ES)6e68ca4c-fe07-4278-bd95-1afbb79714d2 Netherlands (NL)d930dbf9-748d-45b2-a1a8-47f2ccd1c44d Bulgaria (BG)5934e348-5f4f-4876-8065-3c684e919acd Sweden (SE)6e68ca4c-fe07-4278-bd95-1afbb79714d2 Netherlands (NL)3acd809e-c5d0-4f20-91c3-1f3d01b455b4 Poland (PL)f9e3242c-3f43-48ef-8ba4-46b6975a3fdd France (FR)c67644e0-dda8-4107-b8e9-978fdcebea28 Sweden (SE)11f8b80f-ea71-4297-a53f-4258d5d3b90f Germany (DE)1259445e-a1fd-4893-9b9f-08f9edc89b4f Germany (DE)92b4386c-e5ab-444f-95be-43e1758d7166 France (FR)5e4ea114-26ff-402c-acb5-2e5fc34e10d1 Netherlands (NL)8cffde16-12dc-4fce-933f-374d54f4fa47 Spain (ES)13d4e4b4-a0b7-4b0e-a670-bf1e01e9dc3d Poland (PL)383e131d-8ac9-464b-891c-edec40806df8 Norway (NO)4edfba22-9fdd-4b59-8ab8-17d5ad0e1490 Finland (FI)fa2a42d4-3bc2-4227-a0c8-cd97d76849db Netherlands (NL)ed0d7f17-8e19-4ea9-a0c0-ae7a50079494 Germany (DE)d5a17c63-7902-4635-832b-0cb8363bedac Denmark (DK)f0964070-7e0c-4541-9359-2d1975aa9945 Germany (DE)54f8c0e4-78d5-4efc-bb4a-e7bf97518408 Croatia (HR)7508a0e6-9533-4ab0-bfe5-bc229327607a Czech Republic (CZ)a9f952fd-daf0-4a35-9c2f-b2a31a011ae8 Poland (PL)18281490-6f95-4f80-a336-0e6b162be180 Netherlands (NL)d308258b-32b9-4087-bf09-6a66e3109ef4 Netherlands (NL)0a45d19b-4a2a-440f-af7c-53ac264325b3 Estonia (EE)fdd57062-d9fc-4bfd-9079-4a3a96ea94b1 Greece (GR)fb836575-46ef-4da4-9067-d404dc5946bb Portugal (PT)d930dbf9-748d-45b2-a1a8-47f2ccd1c44d Bulgaria (BG)5934e348-5f4f-4876-8065-3c684e919acd Sweden (SE)3acd809e-c5d0-4f20-91c3-1f3d01b455b4 Poland (PL)f9e3242c-3f43-48ef-8ba4-46b6975a3fdd France (FR)
