Warner Electric 6001-448-004
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Warner Electric 6001-448-004 is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Specifications
- Ambient Operating Temperature Range [Imperial]
- -23° to 116°F (-31° to 47°C)
- Auxilliary Supply
- null
- Customer Supplied Switching Options
- Relay D.C.
- Input
- 120 VAC, 50/60 Hz
- Inputs
- 120 VAC
- Max Cycle Rate
- Limited by the clutch or brake, variable with application
- Model
- CBC-801-1
- Mounts
- Two versions of octal socket are available:Foot mount and DIN rail mount.
- Number of Channels
- 2
- Output
- 90 VDC, 1.25 A max
- Output Channel
- Dual
- Overexcitation
- No
- Product Series
- CBC
- Rectification Circuits
- Yes
- Solid State Switching (max leakage current <2mA)
- Not Applicable
- Status Indicator
- Red LED indicates brake is energized, Green LED indicates clutch is energized.
- Suppression Circuits
- Yes
- Switching
- Single pole, double throw.Minimum contact rating: 10 Amp, 28 VDC resistive or 10 Amp, 120 VAC inductive
- UL Listed
- Yes
