NOSHOK 800-0/300-1-1-8-8-025-6

Specifications

• 1800 Series Attachable Loop-Powered Digital Indicators
  • NOSHOK 1800 Series Attachable Loop-Powered Digital Indicators can be fitted to certain NOSHOK pressure transmitters utilizing a 4 mA to 20 mA output signal and the DIN EN 175301-803 Form A Electrical Connection.
• Ambient Temperature Range
  • -40 to 85 ºC, -40 to 185 ºF
• Approximate Weight
  • 4 oz
• Electrical Protection
  • Reverse polarity, over-voltage and short circuit protection
• Industry Standards/Certifications
  • European Conformity (CE) Compliant to Electromagnetic Compatibility (EMC) Norm European Standards (EN) 61326:1997/A1:1998, Radio Frequency Interference (RFI), Electromagnetic Interference (EMI) and Electrostatic Discharge (ESD) Protection
• Load Limitations
  • ≤(VPower - 10)/0.020 Amp for 4 to 20 mA output ≤5000 Ω for 1 to 5 Vdc output ≤10, 000 Ω for 0 to 10 Vdc output ≤4500 Ω for 0.5 to 4.5 Vdc output
• Measuring Element
  • Class B per Norm European Standards (EN) 60751 (International Electrotechnical Commission (IEC 751))
• Operating Temperature [Max]
  • 300 ºF
• Output
  • ±[0.30 + 0.005 ltl] ºC ±0.5% Full Scale
• Output Signal
  • 4 to 20 mA, 2-Wire
• Power Supply
  • 10 to 30 Vdc (4 to 20 mA, 2-Wire) 10 to 30 Vdc (0 to 5 Vdc, 3-Wire) 10 to 30 Vdc (1 to 5 Vdc, 3-Wire) 14 to 30 Vdc (0 to 10 Vdc, 3-Wire)
• Pressure Rating
  • 725 psi
• Seal Material
  • 316 Stainless Steel
• Sensing Temperature [Max]
  • 85 ºC, 185 ºF
• Sensing Temperature [Min]
  • -40 ºC, -40 ºF
• Sensor Length
  • 2.5 in
• Sensor Protection
  • Burnout Protected from 3.3 to 23 mA
• Series
  • 800
• Standard Temperature Ranges
  • -40 to 120|50 to 400 ºF
• Thermowells
  • Thermowells allow a temperature instrument to be removed and replaced without shutting down and draining the process, and reduce the possibility of damage to the temperature instrument.
• Type
  • Transmitter
• Warranty
  • 3 yr
