NOSHOK 40-310-5000-psi

Specifications

• Accuracy
  • 1.0 %
• Ambient Temperature Range
  • -18 to 71 ºC, 0 to 160 ºF
• Assembly Options
  • NOSHOK offers multiple assembly options to meet your specific system requirements. Consult factory to discuss your customized solution.
• Case Type
  • Brass, Back Connection
• Connection Location
  • Back
• Cover Ring Material
  • Polished Brass
• Dial/Display Size
  • Aluminum, white background with black scale. UV resistant.
• Diaphragm Seals
  • NOSHOK offers a wide variety of standard & elevated pressure, and reduced pressure replaceable and non-replaceable diaphragm seals, designed to isolate and/or protect the pressure measuring instrument from corrosive, viscous, contaminated or very high temperature process media.
• Distribution Manifolds
  • NOSHOK's Distribution Manifolds connect multiple instruments to one diaphragm seal, eliminating multiple connections that lead to possible leak paths.
• Fill Liquid
  • Glycerin
• Gauge Size
  • 4 in
• Installed Options and Accessories
  • Available Maximum Indicating Pointer (MIP) Glass Lens Overlay (GLO) Safety Glass Overlay (SGO) Chrome Front Flange (CFF) Chrome Front Flange w/o Holes (CFFN) Brass Front Flange (BFF) Rear Flange (RF) Chrome Cover Ring (CCR) Increased Accuracy from 1.5% to 1.0% (IA) SAE J1926-3:7/16-20 Adjustable Connection (SST) Includes FKM O-ring. Consult factory for availability. 10-32-UNF-2B (10-32) Orifice - Brass Threaded 0.3mm (BT3) Orifice - Brass Threaded 0.4mm (BT4) Orifice - Brass Threaded 0.8mm (BT8) - Standard Rubber Case Protectors (RCP) Laser Marking (LM) Stainless Steel Tagging (ST) Gauge Fill Options Silicone (SL) Halocarbon (HL) -40 Degree Service (GY40) Mineral Oil (MO) Certificates Certified Calibration (CC) Cleaning for Oxygen Service (O 2 ), Up to 1000 psi Cleaning for Oxygen Service (O 2 ), 1500 psi and up
• Lens/Display Material
  • Acrylic with O-Ring Seal
• Material
  • Die Cast Brass (Natural Brass Finish) with Safety Relief Plug
• Media Temperature Range
  • -20 to 60 ºC, -4 to 140 ºF
• Metric Dials and Customized Special Dials
  • Dual scale metric dials in psi/bar, psi/kPa and psi/kg/cm 2 Other scales are available for specific sizes and ranges, such as single scale bar and kPa, refrigerant scales and altitude scales Customized special dials such as non-standard metric scale, tons of ram, lbs. of force, etc. are available in small quantities (as few as one piece) on some NOSHOK gauges Please consult the factory for availability.
• Movement
  • Brass and Nickel-Silver with Highly Polished Bearing Surfaces
• Optional Temperature Range
  • -40 to 100 ºC, -40 to 212 ºF
• Pointer
  • Balanced Aluminum, Black Finish
• Pressure Range
  • 0 to 5,000 psi
• Refrigeration Gauges with Dials Reading in Pressure and Temperature
  • Refrigeration gauges with dials reading in pressure and temperature are available in NOSHOK 300, 400 and 500 Series Pressure Gauges for R-12 and R-22
• Scale Option
  • psi Single Scale
• Series
  • 300
• Steam Syphons
  • Protect the instrument from the damaging effects of high temperature steam Recommended for use in all steam applications Available in 1/4" and 1/2" NPT sizes in welded steel, welded 316 Stainless Steel or seamless 316 Stainless Steel with ratings to 3800 psi at 850 ºF
• Stock
  • Yes
• Swivel Adapters
  • Temperature ratings: 15,000 psi at 200 ºF and 3000 psi at 1000 ºF Used with gauges and gauge valves to adjust the line of sight Rotates 360º to allow the connected instrument to be positioned in the desired direction The pressure connection is achieved with a tapered cone style compression fitting simply by tightening the swivel hex nut All 316 Stainless Steel construction Standard with 1/2" NPT male process - 1/2" NPT female instrument connections Also available with 1/4" NPT connections, same specifications apply Weight approximately 0.8 lb.
• Type
  • Pressure Gauge
• Uninstalled Options and Accessories
  • Chrome Adaptor Ring (25-13-1-CHROME-AR) Rubber Case Protector (25-123459-0-RCP) Certificate of Cleaning (COCL) Certificate of Conformance (COC)
• Warranty
  • 3 yr
• Working Pressure Limitations
  • Dynamic Pressure The working pressure should be limited to 60% of the dial range Static Pressure The working pressure, where no sharp fluctuations occur, should be limited to 90% of the dial range
