Description
The ATR0-420-24L-SP AC Current Transducer combines a current transformer and signal conditioner into a single package. This current transducer has two jumper-selectable current input ranges and an industry standard 4Ð20 ma proportional analog output. The ATR0-420-24L-SP AC Current Transducers is a True RMS signal conditioner and a current transformer in a single package. The ATR Series provides True RMS output on distorted waveforms found on VFD or SCR outputs, and on linear loads in ÒnoisyÓ power environments. This model features a split-core case with top mounted terminals. Jumper selectable ranges of 0-2 amps and 0-5 amps. Requires a 24VDC loop powered power supply.ATR0-420-24L-SP, True RMS Current Transducers, Split-Core, 24L - 24 VDC Loop-Powered
NK Technologies ATR0-420-24L-SP is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Specifications
- Accuracy
- 1.0% FS
- Case
- UL 94V-0 Flammability rated thermoplastic
- Case Style
- Split-core
- Environmental
- -4 to 122°F (-20 to 50°C),0-95% RH non-condensing
- Frequency Range
- 10-400 Hz
- Input Range
- 2, 5 A
- Isolation Voltage
- UL listed to 1270 VAC, tested to 5 KV
- Listing
- UL and ULC Listed, CE Certified
- Output Impedence
- <750 Ω @ 24 VDC
- Output Limit
- 23 mA
- Output Signal
- 4-20 mA loop-powered, average or True RMS
- Power Supply
- 24VDC (12-40 VDC)
- Response Time
- 600 ms (to 90% step change)
- Sensor Type
- AC Current Transducer
- Shipping Weight
- 0.4 lbs
