NK Technologies AT4-420-24L-FL
Free Shipping
1 Year Warranty
A+ Rated On The BBB
Next Day Delivery
Based In The USA
Description
The AT4-420-24L-FL AC Current Transducer combines a current transformer and a signal conditioner into a single package. The AT4-420-24L-FL AC Current Transducer is designed for average responding, for use on linear (sinusoidal) loads. This model produces an industry standard proportional 4-20ma analog output signal. It features a solid-core case with jumper selectable current ranges of 0-1000 amps, 0-1333 amps and 0-2000 amps. This model uses a 24VDC loop powered power supply.AT4-420-24L-FL, Average Responding Current Transducers, Solid-Core, 24L - 24 VDC Loop-Powered
NK Technologies AT4-420-24L-FL is now available new, surplus, and used from Williams Automation.
If you need a specific firmware or series relating to this item, please call or email us with your request.
We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you require one.
Please note we offer UPS Next Day Air shipping for all orders. Please be sure to select next day shipping at checkout, and we will provide same-day shipment.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Specifications
- Accuracy
- 1.0% FS
- Case
- UL 94V-0 Flammability rated thermoplastic
- Case Style
- Split-core, Base Terminals
- Environmental
- -20 to 50 Deg. C, (-4-122 Deg F) 0-95% RH, non-condensing
- Frequency Range
- 50-60 Hz (Sinusoidal)
- Input Range
- 0-1000, 0-1333 & 0-2000 A Jumper Selectable
- Isolation Voltage
- UL listed to 600 VAC, tested to 5 KV
- Listing
- UL and ULC Listed, CE Certified
- Measurement
- Average Responding
- Output Impedence
- <750 Ω @ 24 VDC
- Output Limit
- 23 mA
- Output Signal
- 4–20 mA loop-powered, average
- Power Supply
- 24VDC Nominal
- Response Time
- 600 ms (to 90% step change)
- Sensor Type
- AC Current Transducers
- Shipping Weight
- 1.4 lbs
