Intermatic IG2240-PK
Free Shipping
1 Year Warranty
A+ Rated On The BBB
10% Off First Order
Based In The USA
Description
Intermatic's Smart Guard® Whole House Surge Protective Device provides coverage of your customer’s big investment equipment, from appliances and computers, to HVAC equipment and TVs. This innovative SPD uses the IMODULE® with LED lights for quick and easy indication when protection has been compromised. A blue light indicates the SPD unit is ON and a green light indicates surge protection is active. Trusted, state-of-the-art TPMOV® (Thermally Protected Metal Oxide Varistor) surge protection technology eliminates the potentially hazardous failure modes that are commonly associated with standard MOV technology. Type 1 applications include outdoor installations before service entrances and utility meter cabinets. Type 2 applications include installations after service entrances. UL Listed to ANSI/UL 1449 3rd editionSurge Protective Device, 6-Mode, 120/240 VAC 1Ph, Type 2, Outdoor Plastic, Connected Equipment Warranty 10yr $25,000
Intermatic IG2240-PK is now available from Williams Automation.
If you need a specific firmware version or series for this item, please call or email us with your request. We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you need one.
We offer Overnight shipping for most items listed on our website. Please get in touch with us to confirm whether the product can ship overnight on the day of your order. Cutoff times are typically 2-3 PM EST. Lead times can range from 1 to 4 business days.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Specifications
- Applications
- Whole Home Protection
- Connected Equipment Warranty Coverage
- 25000
- Connected Equipment Warranty Period
- 10-Year limited
- Country of Origin
- Mexico
- Enclosure Type
- Indoor/outdoor type 3R plastic
- Input Voltage Ranges
- 120/240 VAC, 50/60 Hz
- LED Surge Protection Indicator
- Blue; Green
- Lifecycle
- Production
- Market
- Residential
- Maximum Surge Current Rating Per Phase
- 50 kA
- Modes Of Protection
- 6 (L1-N, L2-N, L1-G, L2-G, N-G, L1-L2)
- Nominal Discharge Current
- 10 kA
- Number Of Wire Leads
- 4
- Operating Temperature Max
- 185°C
- 85°F
- Operating Temperature Min
- -35°F
- -31°C
- Packaging Applications
- Residential; Light Commercial
- Short Circuit Current Rating
- 10 kA
- Solutions
- Surge Protection
- Surge Protection Technology
- TPMOV®
- Surge Protection Types
- 2
- UL Certification
- cULus
- Unit Carton Description
- EA-Each
- Units Per Pallet
- 216
- Voltage
- 120/240 VAC Single-Phase
- Voltage Protection Rating LG
- 1500
- Voltage Protection Rating LL
- 1200
- Voltage Protection Rating LN
- 800
- Voltage Protection Rating NG
- 700
- Warranty Period
- 10-Year limited (Base) 3-Year limited (Modules)
- Wire Lead Length
- 18 in; 457.2 mm
- Wire Size Max
- #10 AWG, Tinned Copper
- Wiring Option
- Terminals; Wire leads
Voltage
- Maximum Continuous Operating Voltage LG
- 300
- Maximum Continuous Operating Voltage LL
- 300
- Maximum Continuous Operating Voltage LN
- 150
- Maximum Continuous Operating Voltage NG
- 150
