Ingersoll Rand 107XPA
Estimated Delivery between and with free shipping.
Overnight shipping is also available.
Free Shipping
1 Year Warranty
A+ Rated On The BBB
Next Day Delivery
Based In The USA
Description
Ingersoll Rand 107XPA is now available new, surplus, and used from Williams Automation.
If you need a specific firmware or series relating to this item, please call or email us with your request.
We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you require one.
Please note we offer UPS Next Day Air shipping for all orders. Please be sure to select next day shipping at checkout, and we will provide same-day shipment.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Specifications
- Actuation/Throttle Type/Switch Type
- Lever
- Air Consumption (cfm)
- 19
- Air Consumption (l/min)
- 530
- Air Inlet NPT (in)
- 1/4
- Air Pressure (psi)
- 90
- Average Air Consumption (cfm)
- 4
- Average Air Consumption (l/min)
- 113
- Configuration/Handle Type
- Inline
- Country of Origin
- China
- Drive Size (in)
- 3/8
- Duty Rating
- Industrial Duty
- Exhaust Location
- Side - Adjustable
- Free Speed (rpm)
- 160
- Handle Material
- Aluminum
- Height
- 1.72 in
- Housing Material
- Aluminum
- Length
- 11 in
- Max Bolt Capacity Sae Grade 5 Bolt Diameter (in)
- 7/16
- Max Reverse Torque (ft-lb)
- 54
- Max Reverse Torque (nm)
- 73
- Min Hose Size (in)
- 3/8
- Number of Power Settings
- Continuous
- Power Source
- Air Powered
- Prime Location
- Charlotte, NC
- Product Height (mm)
- 44
- Retainer Type
- Ball
- Reversible
- Reversible
- Side to Center Distance (in)
- 0.96
- Sound Pressure/Power Db(A)
- 94.4 / 105.4
- Speed Setting
- Variable Speed
- Standards/Certifications
- All Gov Regulations And Fda Certified
- Torque Range (ft-lb)
- 10-45
- Torque Range (nm)
- 14-61
- Vibration Level (m/s2)
- 2.4
- Warranty
- 1-year
- Weight
- 2.75 lb
- Width
- 1.91 in
Williams Automation sells Ingersoll Rand parts at huge savings. Search to find the part you need today. If you can't find what you are looking for please Request A Quote from us and we will provide a timely response. You can also call us at 803-761-7027. We look forward to working with you to assist in the best way we can for your industrial needs.
