Boston Gear RF726-20-B5-J
Free Shipping
1 Year Warranty
A+ Rated On The BBB
Next Day Delivery
Based In The USA
Description
Our standard 700 Series - the heart of Boston Gear's speed reducer product line - has been serving many industries reliably for over 40 years. Its proven modular design has set the industry standard for performance and is the most imitated product in today's worm gear speed reducer market. But why settle for a knock-off when you can have the original - from Boston Gear.RF726 S/R Red. 20:1 Ratio, No Base, "J" Assy
Boston Gear RF726-20-B5-J is now available new, surplus, and used from Williams Automation.
If you need a specific firmware or series relating to this item, please call or email us with your request.
We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you require one.
Please note we offer UPS Next Day Air shipping for all orders. Please be sure to select next day shipping at checkout, and we will provide same-day shipment.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Specifications
- AGMA Service Class
- I
- Base/Mounting Attachment
- No Base
- Center Distance Code
- 726
- Center Distance [Imperial]
- 2.62 in
- Fan Cooled
- No
- Flange
- Yes
- Input Motor HP
- 2 HP at AGMA Service Class I
- Input Power Range [Imperial]
- 2.01 - 3.00
- Input Power Range [Metric]
- 1.566 - 2.311
- Input Power Rating [Imperial]
- 2.34 HP
- Input Power Rating [Metric]
- 1.745 kW
- Input Style
- RF Coupled Flange
- Material
- Cast Iron, Standard Paint
- Motor Frame Size
- B5 - 56C
- Output Bore/Shaft Diameter [Imperial]
- 1-1/8 in
- Output Shaft
- Solid
- Output Shaft Projection
- J Solid Right Output
- Output Speed
- 87.5 RPM
- Output Torque Rating [Imperial]
- 1,483 lb-in
- Output Torque Rating Range [Imperial]
- 1000 - 1499
- Output Torque Rating Range [Metric]
- 160 - 234
- Pre-Lubricated
- No
- Rated Efficiency
- 0.88
- Ratio
- 20:1
- Ratio and Output Speed
- 20:1 | 87.5 RPM
- Ratio and Output Speed Range
- 11:1 thru 20:1 | 175 RPM thru 87 RPM
- Recommended Lubrication
- Klubersynth UH1 6-460
- Reduction
- Single
- Reduction Type
- Single Reduction Right Angle
- Style
- Right Angle
