American Control Electronics VFD603-5
Free Shipping
1 Year Warranty
A+ Rated On The BBB
Next Day Delivery
Based In The USA
Description
The VFD603 Series have all the features of the original VFD Series with several enhancements. They include a rugged steel or plastic NEMA 4X enclosure, an isolated front end, minimum speed adjustment potentiometer (pot), output voltage doubling, DC injection braking, and automatic or manual restart when power is restored. The VFD603 Series accepts reference signals that are 0-5 VDC, 0-10 VDC or 4-20 mA without an additional isolation card. The DC injection braking feature comes with two additional calibration potentiometers (Braking Current and Braking Time) for easy set up. There is never a need to program the VFD603 Series. The dual voltage VFD603 Series has a “doubling” jumper that can be set to output 230 VAC to the motor when only 115 VAC is available. Another jumper selectable option is for choosing automatic or manual restarting. The features, fl exibility and compact size of the VFD603 Series make it the ideal choice for AC motor applications under 1.5 HP in adverse surroundings.VFD Series VFD603-5
American Control Electronics VFD603-5 is now available new, surplus, and used from Williams Automation.
If you need a specific firmware or series relating to this item, please call or email us with your request.
We can also provide specifications and/or a data sheet for this item upon request. Please call or email us if you require one.
Please note we offer UPS Next Day Air shipping for all orders. Please be sure to select next day shipping at checkout, and we will provide same-day shipment.
Call (803) 761-7027 if you have any questions about availability, or email us at sales@williamsautomation.com.
Specifications
- Braking
- No
- Enclosure
- Chassis
- Input Voltage (VAC) Freq (Hz) Phase
- 115 / 230 || 50 / 60 || 1Φ
- Isolation
- 0 - 5, 0 - 10 VDC || 4-20 mA
- Maximum Current (AAC)
- 5.0
- Model Number
- VFD603-5
- Output Freq.(Hz)
- 60
- Output Phase
- 1Φ / 3Φ
- Output Voltage(VAC)
- 0 - 230
- Power Range HP
- 3/8 - 1 1/2
- Power Range KW
- .28 - 1.1
- Reversing
- Yes
